74 Chapter 6—EQ
01V—Owner’s Manual
31 Total EQ 2
PEAKING PEAKING PEAKING H.SHELF
A variation on program
30.
G
+4.0 dB +1.5 dB +2.0 dB +6.0 dB
F
94 Hz 749 Hz 1.78 kHz 17.9 kHz
Q
7 2.8 5.6 —
32 Total EQ 3
L.SHELF PEAKING PEAKING H.SHELF
A variation on program
30. Can also be used
with stereo inputs or
external effect returns.
G
+1.5 dB +0.5 dB +2.0 dB +4.0 dB
F
66 Hz 841 Hz 1.88 kHz 15.1 kHz
Q
— 0.28 0.7 —
33 Bass Drum 3
PEAKING PEAKING PEAKING PEAKING
A variation on program
1. The low and mid
range is removed.
G
+3.5 dB –10.0 dB +3.5 dB 0.0 dB
F
118 Hz 315 Hz 4.23 kHz 20.1 kHz
Q
2 10 0.4 0.4
34 Snare Drum 3
L.SHELF PEAKING PEAKING PEAKING
A variation on program
3. It creates a thick
sound.
G
0.0 dB +2.0 dB +3.5 dB 0.0 dB
F
223 Hz 561 Hz 4.23 kHz 4.00 kHz
Q
— 4.5 2.8 0.1
35 Tom-tom 2
L.SHELF PEAKING PEAKING H.SHELF
A variation on program
5. Emphasizes the mid
and high range.
G
–9.0 dB +1.5 dB +2.0 dB 0.0 dB
F
88 Hz 210 Hz 5.33 kHz 16.9 kHz
Q
— 4.5 1.2 —
36 Piano 3
PEAKING PEAKING PEAKING H.SHELF
A variation on program
13.
G
+4.5 dB –13.0 dB +4.5 dB +2.5 dB
F
99 Hz 472 Hz 2.37 kHz 10.0 kHz
Q
8109—
37 Piano Low
PEAKING PEAKING PEAKING H.SHELF
Use for the low range of
a piano sound recorded
in stereo.
G
–5.5 dB +1.5 dB +6.0 dB 0.0 dB
F
187 Hz 397 Hz 6.72 kHz 12.6 kHz
Q
10 6.3 2.2 —
38 Piano High
PEAKING PEAKING PEAKING PEAKING
Use for the high range
of a piano sound
recorded in stereo.
G
–5.5 dB +1.5 dB +5.0 dB +3.0 dB
F
187 Hz 397 Hz 6.72 kHz 5.65 kHz
Q
10 6.3 2.2 0.1
39 Fine-EQ Cass
L.SHELF PEAKING PEAKING H.SHELF
Use when recording to
or from cassette tape to
make the sound clearer.
G
–1.5 dB –18.0 dB +1.0 dB +3.0 dB
F
74 Hz 1.00 kHz 4.00 kHz 12.6 kHz
Q
— 4.5 1.8 —
40 Narrator
PEAKING PEAKING PEAKING H.SHELF
Use when recording
narration.
G
–4.0 dB –1.0 dB +2.0 dB 0.0 dB
F
105 Hz 707 Hz 2.52 kHz 10.0 kHz
Q
4 7 0.63 —
# Title
Parameter
Description
LOW L-MID H-MID HIGH
