Yamaha DM2000 Service Manual

DM2000
12
MACHINE CONTROL Section
TRACK ARMING
DISPLAY, ALL CLEAR buttons
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19,
20, 21, 22, 23, 24, MASTER, TRACK ARMING GROUP: A, B, C,
D buttons (w/LED)
LOCATOR
DISPLAY button
LOCATE MEMORY: 1, 2, 3, 4, 5, 6, 7, 8, AUDITION, PRE, IN,
OUT, POST, SET, MTR, RETURN TO ZERO, END, ONLINE,
LOOP, QUICK PUNCH, ROLL BACK, REHEARSAL, MASTER but-
tons (w/LED)
TRANSPORT
CONTROL
REW, FF, STOP, PLAY, REC, SHUTTLE, SCRUB (w/LED)
CHANNEL STRIP Section
Encoders
x 24 (1–24)
Buttons
AUTO x 24 (1–24), SEL x 24 (1–24), SOLO x 24 (1–24), ON x
24 (1–24)
Faders (w/ touch
sense)
x 24 (1–24)
MASTER Section
LAYER
Input CH: 1–24, 25–48, 49–72, 73–96, MASTER, REMOTE 1,
REMOTE 2, REMOTE 3, REMOTE 4 buttons (w/LED)
STEREO
AUTO, SEL, ON buttons (w/LED)
Fader (w/touch sense) x 1
DATA ENTRY Section
Buttons
DISPLAY HISTORY: BACK, FORWARD, INC, DEC, , , ,
, ENTER buttons
Encoder
Parameter wheel
PEAK LED
x24 INPUT 1–24
SIGNAL LED
x24 INPUT 1–24
DISPLAY CONTROL Section
DISPLAY
320 X 240 dot graphic LCD (w/contrast control potentiometer)
SELECTED CHANNEL Section
DELAY
MIX, FB LEDs x2
AUX / MATRIX SEND
BANK LEDs x3
DYNAMICS
GATE, COMP LEDs x2
PAN/SURROUND
Pan position LEDs x10
EQUALIZER
FREQUENCY, Q LEDs 2 X 4
dB, Hz, kHz 3 X 4
3-digit numeric LEDs x4 (parameter value)
MONITOR Section SOLO
LED x1
SCENE MEMORY section Scene memory number
2-digit numeric LED x1
CHANNEL STRIP Section
CH NAME, routing,
panning position, EQ,
INS, DLY, COMP, GATE:
on/ off, touch sense
status, etc
2 color VFD (FL) units x3
Indicators
Analog Section
Digital Section

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
