DM2000
15
Input Format Data length Level Connector
2TR IN DIGITAL
1
AES/EBU 24-bit RS422
XLR-3-31 type (Balanced)
*1
*1. XLR-3-31 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
2
AES/EBU 24-bit RS422
XLR-3-31 type (Balanced)
*1
3
IEC-60958 24-bit 0.5 Vpp/75 PHONO
CASCADE IN
RS422
D-SUB Half Pitch Connector 68P
(Female)
Output Format Data length Level Connector
2TR OUT DIGITAL
1
AES/EBU
*1
Professional use
*1. Channel status of 2TR OUT DIGITAL 1, 2
Type: 2 audio channels
Emphasis: NO
Sampling rate: depends on the internal configuration
24-bit
*2
*2. Dither: word length 16/20/24 bit
RS422
XLR-3-32 type (Balanced)
*3
*3. XLR-3-32 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
2
AES/EBU
*1
Professional use
24-bit
*2
RS422
XLR-3-32 type (Balanced)
*3
3
IEC-60958
*4
Consumer use
*4. Channel status of 2TR OUT DIGITAL 3
Type: 2 audio channels
Category code: 2 channel PCM encoder/decoder
Copy prohibit: NO
Emphasis: NO
Clock accuracy: Level II (1000 ppm)
Samplin
g
rate: depends on the internal confi
g
uration
24-bit
*2
0.5V pp/75 Phono
CASCADE OUT
RS422
D-SUB Half Pitch Connec-
tor 68P (Female)
Digital Input Spec
Digital Output Spec
