Yamaha DM2000 Service Manual

DM2000
16
Each I/O SLOT accepts a digital interface card. Only SLOT #1 has a serial interface.
Card Name Function Accept Input Output
Number of
available cards
MY8-AT
ADAT YES 8 IN
8 OUT (depends on output
patch)
*1
*1. See the Digital I/O chapter.
Details depend on each interface card.
6
MY8-TD
TASCAM YES 8 IN
8 OUT (depends on output
patch)
*1
6
MY8-AE
AES/EBU YES 8 IN
8 OUT (depends on output
patch)
*1
6
MY4-AD
ANALOG IN YES 4 IN — 6
MY8-AD
ANALOG IN YES 8 IN — 6
MY4-DA
ANALOG OUT YES —
4 OUT (depends on output
patch)
*1
6
MY8-AD24
ANALOG IN YES 8 IN — 6
MY8-AD96
ANALOG IN YES 8 IN — 6
MY8-DA96
ANALOG OUT YES —
8 OUT (depends on output
patch)
*1
6
MY8-AE96S
AES/EBU YES 8 IN
8 OUT (depends on output
patch)
*1
4
MY8-AE96
AES/EBU YES 8 IN
8 OUT (depends on output
patch)
*1
6
I/O Port Format Level Connector in Console
TO HOST
Serial
— RS422 Mini DIN Connector 8P
USB
USB 1.1 0 V–3.3 V B type USB connector
MIDI
IN
MIDI — DIN Connector 5P
OUT
MIDI — DIN Connector 5P
THRU
MIDI — DIN Connector 5P
TIME CODE IN
MTC
MIDI — DIN Connector 5P
SMPTE
SMPTE Nominal –10 dB/10k Ω
XLR-3-31 type (Balanced)
*1
*1. XLR-3-31 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
WORD CLOCK
IN
—
TTL/75 Ω (ON/OFF)
*2
*2. This switch is on the rear panel.
BNC Connector
OUT 1, 2
— TTL/75 Ω BNC Connector
CONTROL
— — D-SUB Connector 25P (Female)
REMOTE
— RS422 D-SUB Connector 9P (Male)
KEYBOARD
PS/2 — DIN Connector 6P
STORAGE CARD
— — SmartMedia slot
METER
— RS422 D-SUB Connector 15P (Female)
I/O Slot Spec
Control I/O Spec

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
