DM2000
90
not installed
not installed
not used
(for check)
not used
(for check)
to DSP-CN105
to SUB-CN102 to DS-CN001 to DS-CN002 to LCDCOM (INV)-CN903
to DSP-CN104
CPU Circuit Board
Component side
Lithium Battery
Battery VN103500
VN103600(Battery holder for VN103500)
Notice for back-up battery removal
Push the battery as shown in figure,
then the battery will pop up.
Druk de batterij naar beneden zoals
aangeven in de tekening de batterij
springt dan naar voren.
Battery
Battery holder
3NA-V776550-2 3
