Yamaha DRCX - I;O Assignment Change Function; Changing the I;O Assignment

3-23
3
I/O INTERFACE
3-7 I/O Assignment Change Function
3-7 I/O Assignment Change Function
3-7-1 Changing the I/O assignment
The function assigned to each I/O signal can be changed with PRM26 (I/O assignment selection
parameter) setting. Refer to the table on next page when you want to change the I/O assignment.
After changing the I/O assignment, the DRCX controller must be restarted to enable the changes.
n
NOTE
The I/O assignment change function is available on controllers whose version is 18.57 or later.
