DSP-AX620
DSP-AX620
■ TO SERVICE PERSONNEL
Critical Components Information
Components having special characteristics are marked Z
and must be replaced with parts having specifications equal
to those originally installed.
AC LEAKAGE
TESTER OR
EQUIVALENT
EQUIPMENT
UNDER TEST
INSULATING
TABLE
WALL
OUTLET
1
IMPEDANCE SELECTOR
WARNING
Do not change the IMPEDANCE SELECTOR
switch setting while the power to this unit is
on, otherwise this unit may be damaged.
■ FRONT PANEL
SILENT VIDEO AUX
PHONES S VIDEO VIDEO L AUDIO R OPTICAL
6CH INPUTINPUT MODE
INPUT
VOLUME
EFFECTSET MENU
DSP
PROGRAM
BASS TREBLE SPEAKERS
AB
OFF
ONOFFON
STANDBY
/ON
DIGITAL
BASS
EXTENSION
–
+
–
+
SURROUND
DIGITAL
–+
A/B/C/D/E
