Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
94
Key Key DVD DVD MENU LD CD
No. Name
Yamaha 0008 Yamaha 0008 Yamaha 0007 Yamaha 0005 Yamaha 0015
3 1 1 7C-94 1 7C-94 1 7C-17 1 79-11 79-11
4 2 2 7C-95 2 7C-95 2 7C-18 2 79-12 79-12
5 3 3 7C-96 3 7C-96 3 7C-19 3 79-13 79-13
6 4 4 7C-97 4 7C-97 4 7C-1A 4 79-14 79-14
7 5 5 7C-98 5 7C-98 5 7C-1B 5 79-15 79-15
8 6 6 7C-99 6 7C-99 6 7C-1C 6 79-16 79-16
9 7 7 7C-9A 7 7C-9A 7 7C-1D 7 79-17 79-17
10 8 8 7C-9B 8 7C-9B 8 7C-1E 8 79-18 79-18
11 9 9 7C-9C 9 7C-9C 9 7C-1F 9 79-19 79-19
12 0 0 7C-93 0 7C-93 0 7C-16 0 79-10 79-10
13 ENTER INDEX 7C-9E INDEX 7C-9E CHP/TIME 7C-15 INDEX 79-0B 79-0B
14 >10 +10 7C-9D +10 7C-9D +10 7C-5D +10 79-1A 79-1A
15 CH+ DISC+ 7C-8B DISC+ 7C-8B DISC+ – DISC+ 7A-4F 79-4F
16 CH- DISC- 7C-8A DISC- 7C-8A DISC- – DISC- 7A-50 79-50
17 REC REC – RETURN 7C-B7 REC – REC – –
18 DISPLAY DISPLAY 7C-A6 DISPLAY 7C-A6 DISPLAY 7C-13 DISPLAY 79-0A 79-0A
19 PAUSE PAUSE 7C-B3 Up 7C-B4 PAUSE 7C-5A PAUSE 7A-09 79-55
20 SKIP-
SKIP/CHAP- 7C-B9 Left 7C-B5 SKIP/CHAP- 7C-02 SKIP- 7A-0B 79-04
21 PLAY PLAY 7C-B2 Select 7C-B8 PLAY 7C-05 PLAY 7A-08 79-02
22 SKIP+
SKIP/CHAP+ 7C-BA Right 7C-B6 SKIP/CHAP+ 7C-03 SKIP+ 7A-0A 79-07
23 STOP STOP 7C-B5 Down 7C-B3 STOP 7C-5B STOP 7A-06 79-56
24 REW REW 7C-B6 TITLE 7C-B1 REW 7C-06 REW 7A-0D 79-05
25 FF FF 7C-B7 MENU 7C-B2 FF 7C-07 FF 7A-0C 79-06
26
AV POWER DVD POWER 7C-B0 DVD POWER 7C-B0 LD POWER – CD POWER ––
27 TV POWER Punch Through Punch Through Punch Through Punch Through
28 STANDBY Punch Through Punch Through Punch Through Punch Through
29 POWER Punch Through Punch Through Punch Through Punch Through
30 TV VOL+ Punch Through Punch Through Punch Through Punch Through
31 TV VOL- Punch Through Punch Through Punch Through Punch Through
32 TV INPUT Punch Through Punch Through Punch Through Punch Through
33 SLEEP Punch Through Punch Through Punch Through Punch Through
34 MUTE Punch Through Punch Through Punch Through Punch Through
35 VOL+ Punch Through Punch Through Punch Through Punch Through
36 VOL- Punch Through Punch Through Punch Through Punch Through
– : No Code
Key Key TAPE TAPE MD AMP/TUNER
No. Name
Yamaha 0004 Yamaha 0014 Yamaha 0024 AMP 0003 DSP 0013 TUNER 0023
3 1 1 – – 79-85 CD 7A-15 7A-88 7A-E5
4 2 2 – – 79-85 TUNER 7A-16 7A-89 7A-E6
5 3 3 – – 79-87 MD/CD-R 7A-18 7A-8A 7A-E7
6 4 4 – – 79-88 DVD 7A-17 7A-8B 7A-E8
7 5 5 – – 79-89 D-TV 7A-54 7A-8C 7A-E9
8 6 6 – – 79-8A VCR 7A-0F 7A-8D 7A-EA
9 7 7 – – 79-8B PHONO 7A-14 7A-8E 7A-EB
10 8 8 – – 79-8C CBL/SAT 7A-C0 7A-8F 7A-EC
11 9 9 – – 79-8D V-AUX 7A-55 7A-90 –
12 0 0 – – 79-8E EXT.DEC. 7A-87 7A-91 –
13 ENTER INDEX – – – A/B/C/D/E 7A-12 7A-12 7A-12
14 >10 +10 – – 79-8F (VCR2) 7A-13 7A-56 –
15 CH+ CH+ – – – PRESET+ 7A-10 7A-10 7A-10
16 CH- CH- – – – PRESER- 7A-11 7A-11 7A-11
17 REC REC/PAUSE 7A-04 7F-04 79-AF TEST 7A-85 7A-85 7A-85
18 DISPLAY A/B DISPLAY 7A-06 7F-06 79-A5 ON SCREEN 7A-C2 7A-C2 7A-C2
19 PAUSE PAUSE – – 79-A9 Up 7A-98 7A-98 7A-98
20 SKIP- DIR A/SKIP- 7A-07 7F-07 79-AB Left 7A-53 7A-53 7A-53
21 PLAY PLAY 7A-00 7F-00 79-A8 – – –
22 SKIP+ DIR B/SLIP+ 7A-40 7F-0B 79-AE Right 7A-52 7A-52 7A-52
23 STOP STOP 7A-03 7F-03 79-AA Down 7A-99 7A-99 7A-99
24 REW REW 7A-01 7F-01 79-AC TIME/LEVEL 7A-86 7A-86 7A-86
25 FF FF 7A-02 7F-02 79-AD SET MENU 7A-9C 7A-9C 7A-9C
26 AV POWER
TAPE/MD POWER ––– –––
27 TV POWER Punch Through Punch Through Punch Through Punch Through Punch Through Punch Through
28 STANDBY Punch Through Punch Through Punch Through
AMP STANDBY 7A-1E 7A-1E 7A-1E
29 POWER Punch Through Punch Through Punch Through
AMP POWER 7A-1D 7A-1D 7A-1D
30 TV VOL+ Punch Through Punch Through Punch Through Punch Through Punch Through Punch Through
31 TV VOL- Punch Through Punch Through Punch Through Punch Through Punch Through Punch Through
32 TV INPUT Punch Through Punch Through Punch Through Punch Through Punch Through Punch Through
33 SLEEP Punch Through Punch Through Punch Through AMP SLEEP 7A-57 7A-57 7A-57
34 MUTE Punch Through Punch Through Punch Through AMP MUTE 7A-1C 7A-1C 7A-1C
35 VOL+ Punch Through Punch Through Punch Through AMP VOL+ 7A-1A 7A-1A 7A-1A
36 VOL- Punch Through Punch Through Punch Through AMP VOL- 7A-1B 7A-1B 7A-1B
– : No Code
List of the Yamaha Code (NEC Format)
