Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
90
Ref.
No. PARTNO. Description Remarks Markets
NewParts
*
* 1‑3 V7331800 SFLEXIBLEFLATCABLE 37P250mmP=1.25
* 1‑5 V6871600 FRONTPANEL BL
* 1‑5 V6871700 FRONTPANEL GD
* 1‑5 V6871800 FRONTPANEL TI
* 1‑6 V6921900 SUBPANEL BL
* 1‑6 V6922000 SUBPANEL GD
* 1‑6 V6922100 SUBPANEL TI
* 1‑7 V6874400 BUTTON/INPUT BL
* 1‑7 V6874500 BUTTON/INPUT GD
* 1‑7 V6874600 BUTTON/INPUT TI
* 1‑10 V6878900 ESCUTCHEON/INPUT BL
* 1‑10 V6879000 ESCUTCHEON/INPUT GD
* 1‑10 V6879100 ESCUTCHEON/INPUT TI
1‑11 V6003800 ESCUTCHOEN/POWER BL
1‑11 V6003900 ESCUTCHOEN/POWER GD
1‑11 V6004000 ESCUTCHOEN/POWER TI
* 1‑12 V6879800 ESCUTCHEN/D5 BL
* 1‑13 V6879900 SHEET,WINDOW
1‑14 V6001900 BUTTOND5 BL
1‑14 V6002000 BUTTOND5 GD
1‑14 V6002100 BUTTOND5 TI
1‑25 EP630220 BINDHEADP‑TITESCREW 3x8ZMC2‑BL
1‑40 V6034100 EMBLEM BL,TI
1‑40 V6034200 EMBLEM GD
* 2‑8 MF110180 FLEXIBLEFLATCABLE 10P180mmP=1.25
* 2‑101 V6864600 SUBCHASSIS
* 2‑108 V6876500 SUPPORT/PJ BL
* 2‑108 V6876600 SUPPORT/PJ GD
* 2‑108 V6876700 SUPPORT/PJ TI
2‑111 EP600830 BINDHEADB‑TITESCREW 3x8MFC2‑BL
2‑112 VN413300 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2‑BL
* 3‑10 V7558800 HEATSINK
3‑11 VV849300 SHEET 19x24
3‑101 V2461000 SUPPORT,TR
3‑102 VQ368600 PUSHRIVET P3555‑B
3‑103 VK173200 SCREW,TRANSISTOR 3x15SPFCM3
3‑104 VT669300 PWHEADB‑TITESCREW 3x8‑8MFC2
3‑106 EG330030 BINDHEADSCREW 3x6FCRM3‑BL
3‑107 V5454200 DAMPER 2/10/260
* 6 V7208700 P.C.B.ASS'Y OPERATION RT
* 6 V7208800 P.C.B.ASS'Y OPERATION BG
* 7 V7209300 P.C.B.ASS'Y INPUT RT
* 7 V7209400 P.C.B.ASS'Y INPUT BG
* 8 V7209900 P.C.B.ASS'Y DSP
* 9 V7210200 P.C.B.ASS'Y POWER RT
* 9 V7210400 P.C.B.ASS'Y POWER B
* 9 V7210500 P.C.B.ASS'Y POWER G
* 10 V7210900 P.C.B.ASS'Y MAIN RT
* 10 V7211000 P.C.B.ASS'Y MAIN BG
Z * 15 XZ955A00 POWERTRANSFORMER RT
Z * 15 XZ957A00 POWERTRANSFORMER BG
Z 16 VN363700 POWERCORDASS'Y G
Z 16 VV437300 POWERCORDASS'Y B
■ MECHANICAL PARTS
