Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
91
Ref.
No. PARTNO. Description Remarks Markets
NewParts
*
Z 16 VZ542500 POWERCORDASS'Y RT
17 V2438700 CORDSTOPPER 10P1
* 25 MF118200 FLEXIBLEFLATCABLE 18P200mm
26 MF125100 FLEXIBLEFLATCABLE 25P100mm
27 MF227160 SFLEXIBLEFLATCABLE 27P160mm
* 101 V7558900 TOPCOVER BL
* 101 V7559000 TOPCOVER TI
* 101 V7559300 TOPCOVER GD
* 102 V6955500 CHASSIS
* 103 V6867200 REARPANEL RT
* 103 V6867300 REARPANEL B
* 103 V6867400 REARPANEL G
* 109 V6864900 SHIELDCASE
* 110 V6865000 SHIELDCASECOVER
112 V4168900 FRAME,PCB
* 113 V6865400 SUPPORT/PCB‑620
114 VQ775900 GROUNDPLATE
120 V0042500 LEG D60xH21 GD
120 VS025000 LEG D60xH21 BL,TI
121 V6002200 KNOBD43 BL
121 V6002300 KNOBD43 GD
121 V6002400 KNOBD43 TI
* 122 V6877900 KNOB/D18 BL
* 122 V6878000 KNOB/D18 GD
* 122 V6878100 KNOB/D18 TI
123 V6001600 KNOBD15 BL
123 V6001700 KNOBD15 GD
123 V6001800 KNOBD15 TI
* 124 V6876100 BUTTON/D5 BL
* 124 V6876200 BUTTON/D5 GD
* 124 V6876300 BUTTON/D5 TI
* 125 V6877200 PLATE/SIDEL BL
* 125 V6877300 PLATE/SIDEL GD
* 125 V6877400 PLATE/SIDEL TI
* 126 V6877600 PLATE/SIDER BL
* 126 V6877700 PLATE/SIDER GD
* 126 V6877800 PLATE/SIDER TI
135 VR264400 SPACER H8
* 136 V7610900 SHEET/S
* 137 VP857500 DAMPER 4x10x30
138 V2879500 SPACERPCB‑M
139 V7616600 DAMPER
155 VQ368600 PUSHRIVET P3555‑B
160 VN413300 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2‑BL
161 VY731200 BONDINGHEADTAPPINGSCREW 3x10MFNI33
162 EP600830 BINDHEADB‑TITESCREW 3x8MFC2‑BL
163 EP600250 BINDHEADB‑TITESCREW 3x8ZMC2‑Y
166 EG330030 BINDHEADSCREW 3x6FCRM3‑BL
167 VT669300 PWHEADB‑TITESCREW 3x8‑8MFC2
168 VT669400 PWHEADB‑TITESCREW 3x15‑8MFC2
170 21991500 PWHEADS‑TITESCREW 4x8‑10FCRM3‑BL BL
171 21991500 PWHEADS‑TITESCREW 4x8‑10FCRM3‑BL BL
171 VD069600 PWHEADS‑TITESCREW 4x8‑10MFNI‑33 GD
