■ SELF DIAGNOSIS FUNCTION
This product has a built-in self diagnosis function (DIAG) to facilitate inspection, measurement and determination of a faulty
item, if any. There are 14 DIAG menu items each of which has sub-menu items.
Listed in the table below are menu items and sub-menu items.
(Start-up and operation of DIAG menu are executed by using the main unit and its remote control unit.)
DIAG menu
DSP THROUGH
FRONT CH
RAM THROUGH
PRO LOGIC
MARGIN CHECK
MAIN MIX
OTHER INPUT
DISPLAY CHECK
MANUAL TEST
FACTORY PRESET
AD DATA CHECK
IF STATUS
DSP RAM CHECK
VERSION/SUM A: P:
Sub-menu
1. ANALOG BYPASS
2. M, C, R, SW ch
3. Main HPF Check
4. DSP Full Bit
5. DSP Full Bit (F)
6. DSP Full Bit -6dB
1. Front Normal
2. Front Mix
1. 0dB (2ch/Multi)
1. YSS928
1. MAIN 3dB margin
2. MAIN 12dB margin
3. MAIN 18dB margin
1. Center ➝ Main
2. SW ➝ Main
1. External Decoder
1. DISPLAY OFF
2. DISPLAY ALL
3. DISPLAY DIMMER(50%)
4. CHECKED PATTERN 1
5. CHECKED PATTERN 2
1. ALL
2. MAIN L
3. CENTER
4. MAIN R
5. REAR R
6. REAR L
7. LFE
1. INHIBIT (memory initialization inhibited)
2. RESERVED (memory initialized)
1. PANEL KEY0, 1
2. PANEL KEY2, PL
3. DC PROTECTION, PS PROTECTION
1. Inside status
2.
CH status 1
3.
CH status 2
4. CH status 3
5. CH status 4
6. CH status 5
7. BSI-DD 1
8. BSI-DD 2
9. BSI-DD 3
10. BSI-DD 4
11. BSI-DTS 1
12. BSI-DTS 2
13. BSI-DTS 3
14. BSI-DTS 4
15. YSS928-1
16. YSS928-2
17. YSS928-3
1. BUS CHECK
1. Version
2. SUM ALL/PROG
Remote control code (key)
7A---88 (PRG 1)
7A---89 (PRG 2)
7A---8A (PRG 3)
7A---91 (PRG 10)
7A---92 (PRG 11)
7A---03 (TAPE STOP)
7A---8B (PRG 4)
7A---8C (PRG 5)
7A---10 (PRESET +)
7A---8D (PRG 6)
7A---11 (PRESET –)
7A---12 (P. PAGE)
7A---0C (CD FW)
7A---00 (TAPE PLAY)
7A---8E (PRG 7)
7A---8F (PRG 8)
7A---01 (TAPE RW)
7A---02 (TAPE FW)
---------
---------
---------
7A---90 (PRG 9)
7A---04 (TAPE PAUSE)
7A---05 (TAPE MUTE)
7A---06 (TAPE A/B)
7A---07 (TAPE DIR A)
7A---08 (CD PLAY)
7A---09 (CD STOP)
---------
7A---57 (SLEEP)
---------
---------
7A---0B (CD SKIP –)
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
---------
7A---0A (CD SKIP +)
7A---0D (CD REW)
---------
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
To Next Page
