Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
82
P.C.B. MAIN
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
C113 VR325000 C.MYLAR 100pF100V
C114 VR325000 C.MYLAR 100pF100V
C115 VG287500 C.EL 47uF50V
C116 VR325000 C.MYLAR 100pF100V
C117 VR325000 C.MYLAR 100pF100V
C118 VG287500 C.EL 47uF50V
C119 VR325000 C.MYLAR 100pF100V
C120 VR325000 C.MYLAR 100pF100V
C121 UU137470 C.EL 47uF16V
C122 VR325000 C.MYLAR 100pF100V
C123 UA654680 C.MYLAR 0.068uF50V
C124 UA654680 C.MYLAR 0.068uF50V
C125 UA654680 C.MYLAR 0.068uF50V
C126 UA654680 C.MYLAR 0.068uF50V
C127 UA654680 C.MYLAR 0.068uF50V
C128 UR866470 C.EL 4.7uF50V
C129 VR325400 C.MYLAR 0.1uF100V
C130 VR325400 C.MYLAR 0.1uF100V
* C131 VK534000 C.PP 220pF200V
C132 UR866470 C.EL 4.7uF50V
C133 UR866470 C.EL 4.7uF50V
C134 VG287500 C.EL 47uF50V
C135 UR818100 C.EL 100uF6.3V
C136 UA654100 C.MYLAR 0.01uF50V
C137 UA654100 C.MYLAR 0.01uF50V
C138 UA654100 C.MYLAR 0.01uF50V
C139 UA654220 C.MYLAR 0.022uF50V
C140 UA654100 C.MYLAR 0.01uF50V
C141 UA654100 C.MYLAR 0.01uF50V
C142 UA654220 C.MYLAR 0.022uF50V
C143 UA655390 C.MYLAR 0.39uF50V
C144 UA655390 C.MYLAR 0.39uF50V
C145 UA654100 C.MYLAR 0.01uF50V
C146 UA654100 C.MYLAR 0.01uF50V
* C251 UT653100 C.PP 1000pF100V
C252 V2290000 C.EL 22uF63V
C253 VQ462600 C.MYLAR 220pF50V
C254 UU137100 C.EL 10uF16V
C255 UA652220 C.MYLAR 220pF50V
C256 VQ462600 C.MYLAR 220pF50V
C257 UU137100 C.EL 10uF16V
C258 UA652220 C.MYLAR 220pF50V
C259 UA652220 C.MYLAR 220pF50V
C260 Vi578700 C.EL 10uF50V
C261 UA652220 C.MYLAR 220pF50V
C262 UA652220 C.MYLAR 220pF50V
C263 Vi578700 C.EL 10uF50V
C264 UA652220 C.MYLAR 220pF50V
C265 VQ462600 C.MYLAR 220pF50V
C266 UU137100 C.EL 10uF16V
C267 UA652220 C.MYLAR 220pF50V
C268 UU138100 C.EL 100uF16V
C269 V2290000 C.EL 22uF63V
C270 UA653100 C.MYLAR 1000pF50V
C271 VQ245400 C.PP 33pF200V
C272 VG291300 C.EL 100uF50V
C273 UA653100 C.MYLAR 1000pF50V
C274 VQ245400 C.PP 33pF200V
C275 VG291300 C.EL 100uF50V
C276 UA653100 C.MYLAR 1000pF50V
C277 VS696700 C.CE 33pF500V
C278 V4578900 C.EL 47uF35V
C279 UA653100 C.MYLAR 1000pF50V
C280 VS696700 C.CE 33pF500V
C281 V4578900 C.EL 47uF35V
C282 UA653100 C.MYLAR 1000pF50V
C283 VQ245400 C.PP 33pF200V
C284 VG291200 C.EL 47uF50V
C331 UA654330 C.MYLAR 0.033uF50V
C332 VI716300 C.MYLAR 4700pF50V
C333 VI716300 C.MYLAR 4700pF50V
C334 VI716300 C.MYLAR 4700pF50V
C335 VI716300 C.MYLAR 4700pF50V
C336 UA654330 C.MYLAR 0.033uF50V
C339 VI716700 C.MYLAR 0.01uF50V
C340 VI716700 C.MYLAR 0.01uF50V
C341 UA654220 C.MYLAR 0.022uF50V
C342 UA654220 C.MYLAR 0.022uF50V
C343 UA654220 C.MYLAR 0.022uF50V
C344 UA654220 C.MYLAR 0.022uF50V
Z C371 V2922200 C.EL 12000uF63V
Z C372 V2922200 C.EL 12000uF63V
C373 VR325100 C.MYLAR 0.01uF100V
C374 VR325400 C.MYLAR 0.1uF100V
C375 VG291300 C.EL 100uF50V
C376 VG291300 C.EL 100uF50V
C377 VR325400 C.MYLAR 0.1uF100V
C378 UA655100 C.MYLAR 0.1uF50V
C379 UA655100 C.MYLAR 0.1uF50V
C381 VF466900 C.CE.TUBLR 470pF50V BG
C382 VF466900 C.CE.TUBLR 470pF50V BG
C383 VF466900 C.CE.TUBLR 470pF50V BG
C384 VF466900 C.CE.TUBLR 470pF50V BG
C385 VF466900 C.CE.TUBLR 470pF50V BG
C386 VF466900 C.CE.TUBLR 470pF50V BG
C386 VF466900 C.CE.TUBLR 470pF50V
D101 VN008700 DIODE 1SS270A
D102 VN008700 DIODE 1SS270A
D103 VN008700 DIODE 1SS270A
D104 VN008700 DIODE 1SS270A
D105 VN008700 DIODE 1SS270A
D106 VD631600 DIODE 1SS133,176
D107 VD631600 DIODE 1SS133,176
D108 VN008700 DIODE 1SS270A
D109 VN008700 DIODE 1SS270A
D110 VN008700 DIODE 1SS270A
