Yamaha DTX-Multi 12 - Page 22

DTX-MULTI 12
22
JK Circuit Board
B’
B
to JK-CN302 to JK-CN303
to JK-CN301
to PN-CN501
to LCD MODULEnot installednot installed
Component side
（部品側）
DM Circuit Board
JK: 2NA-WR84760
1
DM: 2NA-WR84750
