PERIODIC MAINTENANCE
2-14
1
2
3
4
5
6
7
8
9
10
PERIODIC CHECKS AND ADJUSTMENTS
ENGINE SPEED (EH63K/EH64A/EH64K/EH65A/
EH65B)
1. Warm up the engine for several minutes.
2. Remove:
• Air filter cover “1”
(Refer to “AIR FILTER” on page 3-3.)
3. Attach:
• Digital tachometer “1”
4. Measure:
• High engine speed (with no load)
Out of specification  Adjust.
Measurement steps:
a. Move the throttle lever “1” to the high engine
speed position “a”.
b. Check that the high engine speed is the specified
valued.
5. Measure:
• Low engine speed (with no load)
Out of specification  Adjust.
1
1
Digital tachometer:
90890-06760, YU-39951-B
High engine speed:
3200–3400 r/min
1
a
Low engine speed:
1500–1700 r/min
