Yamaha EH63 - Installing the Tci Units

TCI UNITS, FLYWHEEL AND STATOR COIL ASSEMBLY
3-23
1
2
3
4
5
6
7
8
9
10
ENGINE
4. Install:
•TCI unit
• TCI unit bolt
(Refer to “INSTALLING THE TCI UNITS” on page
3-23.)
5. Install:
• Cylinder covers
(Refer to “CYLINDER COVERS” on page 3-17.)
6. Install:
• Rectifier/regulator
(Refer to “RECTIFIER/REGULATOR” on page
3-13.)
7. Install:
• Fan case and fan
(Refer to “INSTALLING THE CASE AND FAN” on
page 3-16.)
8. Install:
• Air filter
(Refer to “AIR FILTER” on page 3-3.)
9. Install:
• Muffler
(Refer to “INSTALLING THE MUFFLER” on page
3-9.)
INSTALLING THE TCI UNITS
The following procedure applies to all of the TCI units.
1. Install:
•TCI unit
• TCI unit bolt
Sheave holder:
90890-01701
Primary clutch holder:
YS-01880-A
TCI unit bolt:
8 N·m (0.8 kgf·m, 5.9 lb·ft)
T
R
.
.
TCI unit bolt:
8 N·m (0.8 kgf·m, 5.9 lb·ft)
T
R
.
.
