Yamaha EH63 - Eh65 A;Eh72 A

MUFFLER
3-8
1
2
3
4
5
6
7
8
9
10
ENGINE
EH65A/EH72A
Order Job/Parts to remove Q’ty Remarks
Removing the muffler Remove the parts in the order listed.
1 Muffler cover 1
2 Muffler 1
3Gasket 2
4 Muffler bracket 1
1
2
4
(2)
(2)
3
3
8 N・m (0.8 kgf・m, 5.9 lb・ft)
18 N・m (1.8 kgf・m, 13 lb・ft)
18 N・m (1.8 kgf・m, 13 lb・ft)
8 N・m (0.8 kgf・m, 5.9 lb・ft)
