ENGINE INSPECTION
3-2
1
2
3
4
5
6
7
8
9
10
ENGINE
Testing steps (below the minimum specification):
a. Squirt a few drops of oil into the cylinder.
b. Measure the compression again.
Testing steps (above the maximum specification):
a. Check the cylinder head, valve surfaces, and pis-
ton crown for carbon deposits.
Carbon deposits Eliminate.
5.
Install:
• Spark plug
• Spark plug cap
Reading Diagnosis
Higher than
without oil
• Worn cylinder, piston, and piston ring(s)
Same as
without oil
• Defective piston, piston ring(s), valve(s), and
cylinder head gasket
• Improper valve timing and valve clearance
Spark plug:
13 N·m (1.3 kgf·m, 9.6 lb·ft)
