Yamaha F300A - Neutral Interlock Trigger; Free Throttle Switch

Components
25
Digital electronic control for twin type has the
function to automatically synchronize both
engine speeds.
Also digital electronic control for triple type
has the function to automatically synchronize
the engine speeds of the center engine and
starboard side engine, adapting the port side
engine speed.
The functions of the control lever for triple-
type digital electronic control are as follows.
● Operate the port side engine using the port
side control lever.
● The center engine runs at the average
speed of port side and starboard side en-
gines’ speeds.
● Operate the starboard side engine using
the starboard side control lever.
EMU26201
Neutral interlock trigger
To shift out of neutral, first pull the neutral in-
terlock trigger up.
EMU35832
Free throttle switch
In neutral, keep this switch pressed, move
the control lever forward, and release the
switch after the digital electronic control-ac-
tive indicator starts blinking. While the indica-
tor blinks, you can open or close the throttle.
This can also be done when the control lever
is set in reverse.
Single type
1. Neutral “ ”
2. Forward “ ”
3. Reverse “ ”
4. Shift
ZMU06228
1
N
2
F
3
44
55
6
6
7
7
R
ZMU05878
N
1
F
7
6
2
R
3
4
4
6
5
7
5
5. Fully closed
6. Throttle
7. Fully open
1. Neutral interlock trigger
ZMU06285
1
ZMU06231
N
F
