Operation
76
motor trim angle may have little effect on the
trim of the boat when operating.
EMU27946
Tilting up and down
If the engine will be stopped for some time or
if the boat is moored in shallows, the out-
board motor should be tilted up to protect the
propeller and lower case from damage by
collision with obstructions, and also to re-
duce salt corrosion.
EWM01543
Make sure that all people are clear of the
outboard motor when tilting the outboard
motor up and down. Body parts can be
crushed between the outboard motor and
the clamp bracket when the outboard mo-
tor is trimmed or tilted.
ECM00991
● Before tilting the outboard motor, fol-
low the procedure under “Stopping en-
gine” in this chapter. Never tilt the
outboard motor while the engine is run-
ning. Severe damage from overheating
can result.
● To prevent the cooling water passages
from becoming frozen when the ambi-
ent temperature is 5C or below, tilt the
outboard motor up after it has been
stopped 30 seconds or more.
EMU35508
Procedure for tilting up (power trim
and tilt models)
1. Place the control lever in neutral.
2. Press the power trim and tilt switch “ ”
(up) until the outboard motor has tilted
up completely.
