Instruments and indicators
42
EMU36250
6Y8 Multifunction fuel
management meters
The fuel management meter has the func-
tions of fuel flow meter, total consumption
display, fuel economy display, and remaining
fuel display. The chosen display is selected
by using the “ ” (set) and “ ” (mode)
buttons as described in this section. For
more information, see the operation manual
originally supplied with the meter.
After the main switch is first turned on, all the
displays come on as a test. After a few sec-
onds, the gauge will change to normal oper-
ation.
For more information, see the operation
manual originally supplied with the meter.
EMU41730
Optional meters
Various meters can be installed onto the out-
board motor according to user preference.
For details, consult your Yamaha dealer.
Analog tachometer
1. Speedometer
2. Fuel meter
3. Multifunction display
1. Set button
2. Mode button
1. Fuel flow meter
2. Multifunction display
6AW-9-25-1E0 42 ページ ２０１０年３月１６日 火曜日 午後５時４５分
