Yamaha F300A - Start;Stop Switch Panel; All Start;Stop Switch Panel

Components
31
Triple type
EMU42080
Start/Stop switch panel
The engine can be started or turned off by
pressing the Start/Stop button. For twin and
triple type, it is possible to start or turn off in-
dividual engine. The indicator for the corre-
sponding engine will come on.
● PORT:Port side engine
● CENTER:Center engine
● STBD:Starboard side engine
EMU41631
All Start/Stop switch panel
The Start/Stop button allows all engines to
start or turn off.
ON
OFF
ZMU07146
ON
OFF
START
ON
OFF
START
ON
OFF
START
ZMU05982
ON
OFF
ZMU07146
1. Start/Stop button
1. Indicator
2. Start/Stop button
1
ZMU07173
1
2
ZMU07174
1
2
ZMU07175
