Operation
78
that the trim rods retracts completely
during mooring. This protects the
rods from marine growth and corro-
sion, which could damage the power
trim and tilt mechanism.
[ECM00252]
EMU35515
Procedure for tilting down (power
trim and tilt models)
1. Push the power trim and tilt switch “ ”
(up) until the outboard motor is support-
ed by the tilt rod and the tilt support lever
becomes free.
2. Release the tilt support lever.
3. Push the power trim and tilt switch “ ”
(down) to lower the outboard motor to
the desired position.
