Operation
77
3. Set the tilt support lever to support the
engine. WARNING! After tilting the
outboard motor, be sure to support it
with the tilt support knob or tilt sup-
port lever. Otherwise the outboard
motor could fall back down suddenly
if oil in the power trim and tilt unit or
in the power tilt unit loses pressure.
[EWM00262] NOTICE: Do not use the tilt
support lever or knob when trailering
the boat. The outboard motor could
shake loose from the tilt support and
fall. If the motor cannot be trailered in
the normal running position, use an
additional support device to secure it
in the tilt position. For more detailed
information, see page 82.
[ECM01641]
4. Once the outboard motor is supported
with the tilt support lever, press the pow-
er trim and tilt switch “ ” (down) to re-
tract the trim rods. NOTICE: Make sure
6AW-9-25-1E0 77 ページ ２０１０年３月１６日 火曜日 午後５時４５分
