Yamaha F5A - Water Pump and Shift Rod

8-5
LOWR
Lower unit
Water pump and shift rod
No. Part name Q’ty Remarks
1Bolt 4 M6  45 mm
2Plate 2
3 Rubber seal 1
4 Water pump housing 1
5 Insert cartridge 1
6 Impeller 1
7Gasket 1 
8 Outer plate cartridge 1
9 Rubber seal 1
10 Bolt 1 M6  25 mm
11 Dowel 2
12 Housing 1
13 Shift rod 1
14 Pin 1
15 Pin 1
16 Gasket 1 
15
9
16
14
13
5
6
7
8
10
12
11
1
2
2
4
3
1
