Yamaha F5A - Lighting Coil (Optional for European Market)

2-7
TECH
FEA
Technical features and description
Lighting coil (optional for European market)
The F4B, F5A, F6C can be equipped with a flywheel magnet, lighting coil, and Rectifier Regulator,
available as optional accessories, to enable battery charging.
The electrical current generating capacity is 6A when the engine speed is at 6000 r/min.
a Lighting coil
b Rectifier Regulator
c Fuse
d Battery
e Switch
f Electrical component
a
b
c
d
e
f
