Outboard Rigging Guide - 2001 Quick Start
Mid Size Model(s) 40, C40, F40, 50, C50, F50, T50, 60, C60, 70, C70, F80, 90, C90, F100,
F115
Remote Models
Rigging for Standard Side Mount 703 Control Box
Control Cables (2 req.) ABA-CABLE-XX-GY
Control Box PT & T
(New Switch Main Switch and Safety Lanyard / Push To Open Throttle) OPT 703-48207-15-00
Optional Extension Harness for 10 Pin Main Harness 6.6 ft. OPT 688-8258A-10-00
(Use as needed) 9.8 ft. OPT 688-8258A-30-00
Installing Engine with 704 Single Binnacle or 705 Flush Mount Control Box
Single Binnacle (1 Req.) 704-48205-13-00
or
Flush Mount (1 Req.) 6X0-48206-11-00
Switch Panel Assembly (1 Req.) 704-82570-05-00
Main Harness - 10 Pin (1 Req.) 16.4 ft. OPT 688-8258A-50-00
26 ft. OPT 6K1-8258A-40-00
Optional Extension Harness 10 Pin Main Harness 6.6 ft. OPT 688-8258A-10-00
(Use as needed) 9.8 ft. OPT 688-8258A-30-00
Engine to Tach Harness
2
Non-Oil Injected Engines
No Four Stroke Engines (OPT 1 Req.) 9.8 ft. OPT 6R3-82553-30-00
16.4 ft. OPT 6R3-82553-50-00
22.9 ft. OPT 6R3-82553-70-00
26.2 ft. OPT 6R3-82553-80-00
31.2 ft. OPT 6R3-82553-90-00
Engine to Tach Harness, Trim & Oil Harness
2
Models with Oil Injection and Low Oil Warnings on
Four Stroke Engines 9.8 ft. OPT 64D-82553-30-00
16.4 ft. OPT 64D-82553-50-00
Single Gauge Kit - 23.0 ft. STD 64D-82553-70-00
26.2 ft. OPT 64D-82553-80-00
Dual Gauge Kit - 31.2 ft. STD 64D-82553-90-00
NOTE
1
Order control cables using part number ABA-CABLE-XX-GY substituting the correct footage
needed in place of the XX. Yamaha control cables in 1 ft. increments from 6~30 ft. and in 2 ft.
increments from 32~50 ft.
NOTE
2
If a longer harness is required, you have two choices. Order from the available harnesses, the
length needed, or order additional length trim harnesses to connect to the standard harness (two trim
harnesses will extend one 64D harness). This applies to the oil lamp, trim and oil tank harnesses from 70~250
models.
