Outboard Rigging Guide - 2001 Quick Start
Model(s) V4/V6 115~250 Single Installation All Models — 2-Stroke
Rigging for Standard Side Mount Control Box
Control Cables
1
(2 req.) ABA-CABLE-XX-GY
Control Box with PT & T
(New Main Switch and Safety Lanyard / Push to Open Throttle) 703-48207-15-00
Optional Extension Harness for 10 Pin Main Harness 6 ft. OPT 688-8258A-10-00
9.8 ft. OPT 688-8258A-30-00
Installing Engine with 704 Single Binnacle or 705 Flush Mount Control Box
Single Binnacle 704-48205-13-00
or
Flush Mount (1 Req.) 6X0-48206-11-00
Switch Panel Assembly (New Main Switch and Safety Lanyard) 704-82570-05-00
Main Harness, 10 Pin 16.4 ft. OPT 688-8258A-50-00
(OPT 1 Req. Single Engine) 26 ft. OPT 6K1-8258A-40-00
31.2 ft OPT 61B-8258A-01-00
Optional Extension Harness 10 Pin Main Harness (As Needed) 6.6 ft. OPT 688-8258A-10-00
9.8 ft. OPT 688-8258A-30-00
Engine to Tach Harness, Trim Harness
2
9.8 ft. OPT 6R3-82553-30-00
16.4 ft. OPT 6R3-82553-50-00
22.9 ft. OPT 6R3-82553-70-00
26.2 ft. OPT 6R3-82553-80-00
31.2 ft. OPT 6R3-82553-90-00
Engine to Tach, Trim & Oil Harness
2
(1 Req.) (STD - Rigging Kit)
9.8 ft. OPT 64D-82553-30-00
16.4 ft. OPT 64D-82553-50-00
Single Gauge Rigging Kit -23 ft. STD 64D-82553-70-00
26.2 ft. OPT 64D-82553-80-00
Dual Gauge Rigging Kit - 31.2 ft. STD 64D-82553-90-00
Engine to Oil Tank Harness
2
(1 Req.) (STD - Engine Oil Tank all Precision Blend models) 9.8 ft. OPT 6R3-85721-30-00
16.4 ft. OPT 6R3-85721-50-00
Oil Tank Rigging Kit - 26.2 ft. STD 6R3-85721-80-00
Optional 2.8 Gallon Oil Tank (As Needed) 6YR-W0035-92-00
Optional 5 Gallon Oil Tank (As Needed) 6YR-W0035-C0-00
NOTE
1
Order control cables using part number ABA-CABLE-XX-GY substituting the correct footage
needed in place of the XX. Yamaha control cables in 1 ft. increments from 6~30 ft. and in 2 ft.
increments from 32~50 ft.
NOTE
2
If a longer harness is required, you have two choices. Order from the available harnesses, the
length needed, or order additional length trim harnesses to connect to the standard harness (two trim
harnesses will extend one 64D harness). This applies to the oil lamp, trim and oil tank harnesses from 70~250
models.
