Outboard Rigging Guide - 2001 Quick Start
Yamaha’s counter rotation rigging kits when used in conjunction with a standard single gauge rigging kit, or dual
gauge kit contain all necessary items to install both engine systems (excluding control cables and accessory items.)
Model(s) LF115, L130~L250 Twin Engine Installation
Rigging for Standard Side Mount Control Box
Control Cables (4 Req.) ABA-CABLE-XX-GY
Dual Binnacle (1 Req.) ( STD - LH Rigging Kit) 704-48207-04-00
Switch Panel Assembly (1 Req.) (STD - LH Rigging Kit) 6K1-82570-05-00
(Push to Choke Main Switch)
Main Harness, 10 Pin (2 Req.) (STD - LH Rigging Kit)
Rigging Kit L/H - 26 ft. STD 6K1-8258A-40-00
Rigging Kit L/H - 31.2 ft. STD 61B-8258A-01-00
Optional Extension Harness 10 Pin Main (As Needed) 6.6 ft. OPT 688-8258A-10-00
9.9 ft. OPT 688-8258A-30-00
Engine to Tach, Trim & Oil Harness
2
(1 Req.) (STD - LH Rigging Kit)
Low Oil Warning F115 9.8 ft. OPT 64D-82553-30-00
16.4 ft. OPT 64D-82553-50-00
Single Gauge Kit - 23 ft. STD 64D-82553-70-00
Dual Gauge Kit - 26.2 ft. STD 64D-82553-80-00
L/H Rigging Kit - 31.2 ft. STD 64D-82553-90-00
Engine to Oil Tank Harness
2
(1 Req.) (STD - With Oil Tank. All Precision Blend models) 9.8 ft. OPT 6R3-85721-30-00
16.4 ft. OPT 6R3-85721-50-00
Oil Tank Rigging Kit - 26.2 ft. STD 6R3-85721-80-00
Dual Engine Tie Bar (1 Req.) Shipped in L/H Engine Crate ABA-DUALT-IE-BR
Optional 2.8 Gallon Oil Tank (As Needed) 6YR-W0035-92-00
Optional 5 Gallon Oil Tank (As Needed) 6YR-W0035-C0-00
NOTE
1
Order control cables using part number ABA-CABLE-XX-GY substituting the correct footage
needed in place of the XX. Yamaha control cables in 1 ft. increments from 6~30 ft. and in 2 ft.
increments from 32~50 ft.
NOTE
2
If a longer harness is required, you have two choices. Order from the available harnesses, the length
needed, or order two 6R3-82553-30-00 harnesses to extend 9.8 ft. length standard harness that came with the
rigging kit. This applies to the oil lamp, trim and oil tank harnesses from 70~250 models. For more details, see
the Electrical Section.
