6-50
Outboard Rigging Guide - 2001 C90/90 Tiller Handle &
Steering Friction Kit
INSTALLATION
Neutral Switch
1. Install the neutral switch assembly 1 and
slip plate 2.
2. Install the neutral switch stay 3.
NOTE:Remove the washer and bolt from the
shifter bracket, then install the stay with the
removed washer and bolt.
3. Disconnect the brown lead terminals 4.
4. Connect neutral switch lead 5.
S tart in gear protection will not operate with-
out the neutral switch leads connected.
5. Disconnect the power trim/tilt switch lead
coupler 6.
