Yamaha F80 - Page 343

6A-8
Outboard Rigging Guide - 2001
3. Disconnect:
• Brown lead connector 1
4. Connect:
• Neutral switch connectors 2
STEERING FRICTION
1. Install:
• Steering friction ass’y 1
• Clamp 2
• Bolt with washers (M5) 3
TILLER HANDLE
1. Install:
• Tiller handle ass’y 1
• Nuts 2
• Bolt with washers (M5) 3
2. Install:
• Grommet 1
• Main switch leads 2
• Battery cable 3
• PTT switch lead (for PTT model) 4
• Extension wire harness 5
NOTE:
Align the taped end a of the battery cable
and the extension wire lead with the end of
the grommet.
3. Install:
• Cable stopper 1
• Rubber seal 2
• Remote control cables 3
Nut:
38 Nm (3.8 m•kg, 27 ft•lb)
