6A-11
Outboard Rigging Guide - 2001
13. Install:
• Starter motor 1
• Flywheel magnet cover 2
14 Check:
• Friction force
Turn the friction lever 1 to a or b.
Incorrect → Retighten the nut 2.
15. Check:
• Steering movement 1
• Unsmooth → Repair.
NOTE:
With the friction lver turned fully to the left,
check the tiller for smooth movement.
aa
Friction is increased.
aa
Friction is decreased.
Nut:
5 Nm (0.5 m•kg, 3.6 ft•lb)
