6A-10
Outboard Rigging Guide - 2001
8. Check:
• Fully open positionn
Incorrect → Repair.
9. Connect:
• Main switch connectors 1
10. Connect:
• Extension wire harness coupler 1
11. Connect:
• Overheat and oil warning lamp
coupler 1
• Trim sensor coupler 2
(for PTT model)
12. Connect:
• Trailer/PTT switch couplers 1
(for PTT model)
Checking steps:
• Turn the shift handle in gear position.
• Turn the throttle grip fully open.
• Check the throttle valve lever so that it
contacts the fully opening stopper.
