Yamaha F80 - Page 349

6B-3
Outboard Rigging Guide - 2001
Ref. No. Parts Name Qty. Remarks
1 Tiller handle assembly 1
2 Zip tie 1
3 Neutral switch 1
4 Damper plate 1
5 Switch stay 1
6 Bolt 2
7 Friction rod 1 Steering friction set
8 Link rod 1
9 Bolt 1
10 Washer 3
11 Nut 2
12 Friction control 1
13 Bolt 1
14 Wing nut 1
15 Extension, wire harness 1 10 pin — 12 pin
16 Wire harness 1 12 pin for buzzer, tachometer and trim meter
17 Connector assembly 1
18 Grommet 1
19 Zip tie 1
20 Buzzer 1
21 Buzzer stay 1
