1-8
Outboard Rigging Guide - 2001 Rigging Kits
Tiller Handle Kit for F30/F40 3 Cylinder (67C-W0086-Z1-4D)
Tiller Handle Kit for F50/T50 (62Y-W0086-Z0-4D)
Part Number Part Name Qty.
Tiller Kit Handle Ass’y. 1
Tiller Handle Install. Manual 1
6F5-82540-00-00 Neutral Switch Ass’y. 1
6J8-82554-00-00 Stay, Neutral Switch 1
90109-06M86-00 Bolt 2
65W-44173-00-00 Lever, Shift Control 1
90254-03M05-00 Pin, Slotted Spring 1
62Y-42725-40-00 Grommet 1
63D-83728-00-00 Connector Ass’y. 1
6H5-83553-11-00 Wire, Lead 1
6H2-82586-01-00 Extension Wire Harness 1
Part Number Part Name Qty.
Tiller Kit Handle Ass’y1
Tiller Handle Install. Manual 1
6H2-82586-01-00 Wire Harness Extension 1
6H5-83553-11-00 Read Wire 1
90465-13M36-00 Clamp 1
688-83383-11-00 Buzzer 1
6H5-83386-00-00 Buzzer Stay 1
62Y-42725-40-00 Grommet 1
63D-42546-00-00 Nut 2
63D-42541-00-00 Pipe 2
6F5-82540-00-00 Neutral Switch Ass’y1
62Y-82554-00-00 Stay, Neutral Switch 1
62Y-82555-00-00 Damper, Main Switch 1
90201-08M01-00 Plate Washer 2
63D-42508-00-00 Steering Friction Ass’y1
• 63D-42527-00-00 • Plate, Friction 3 1
• 63D-42526-00-00 • Plate, Friction 2 1
• 63D-42528-00-00 • Piece, Friction 2
• 63D-42562-00-00 • Shaft, Steering Lock 1
• 63D-42561-00-00 • Knob, Steering Lock 1
• 682-43318-01-00 • Cover 1
• 90185-10M01-00 • Nut, Lock 1
97595-08550-00 Bolt 2
97595-06416-00 Bolt 2
97013-05010-00 Bolt 2
90185-10051-00 Nylon Lock Nut 2
62Y-82361-00-00 Clamp, Cord 1
90161-06M03-00 Screw 1
97595-06535-00 Bolt 1
90387-06M26-00 Collar 1
92990-05100-00 Spring Washer 2
95380-05600-00 Nut 2
63D-83728-00-00 Connector Ass’y1
90465-13M24-00 Clamp 1
Steering Friction Ass’y. 1
• 92990-06100-00 • Washer 2
• 90109-06M88-00 • Bolt 2
• 67C-42527-00-00 • Plate, Friction 1
• 95380-05600-00 • Nut 1
• 90387-05M11-00 • Collar 1
• 90387-05M05-00 • Collar 1
• 90119-05M03-00 • Bolt, with Washer 1
• 90202-10M56-00 • Washer, Plate 2
• 65W-42528-00-00 • Plate, Friction 2
• 67C-42525-00-00 • Plate, Friction 1
• 67C-42561-00-00 • Knob, Steering Lock 1
• 689-43633-00-00 • Cover, Tilt Lever 1
• 90209-10M26-00 • Washer 1
• 90185-10M14-00 • Nut, Self-Locking 1
• 67C-42562-00-00 • Shaft, Steering Lock 1
