Yamaha F80 - Page 46

1-9
Outboard Rigging Guide - 2001 Rigging Kits
Tiller Handle Kit for 60/C60/C70/70 (6H3-W0086-Z0-4D)
Tiller Handle Kit for C90/90 (6H3-W0086-Z0-4D)
Part Number Part Name Qty.
Tiller Kit Handle Ass’y1
Tiller Handle Install. Manual 1
6H2-82586-01-00 Wire Harness Extension 1
6H5-83553-11-00 Read Wire 1
90465-13M36-00 Clamp 1
688-83383-11-00 Buzzer 1
6H5-83386-00-00 Buzzer Stay 1
6H2-42725-01-00 Grommet 1
6H3-82540-00-00 Neutral Switch Ass’y1
6H3-82554-00-00 Stay, Neutral Switch 1
663-82555-01-00 Damper, Main Switch 1
Steering Friction Ass’y1
• 663-42518-00-00 • Shaft, Friction 1
• 92990-08600-00 • Plate Washer 2
• 663-42528-00-00 • Piece, Friction 1
• 90175-06003-00 • Nut, Wing 1
• 97080-06035-00 • Bolt 1
• 69242-51501-00 • Rod 1
• 90185-08057-00 • Nut, Lock 1
97013-05010-00 Bolt 2
90185-10051-00 Nylon Lock Nut 2
92990-05100-00 Spring Washer 2
95380-05600-00 Nut 2
63D-83728-00-00 Connector Ass’y. 1
90464-15M11-00 Clamp 3
Part Number Part Name Qty.
Tiller Kit Handle Ass’y1
Tiller Handle Install. Manual 1
6H2-82586-01-00 Wire Harness Extension 1
6H5-83553-11-00 Read Wire 1
90465-13M36-00 Clamp 1
688-83383-11-00 Buzzer 1
6H5-83386-00-00 Buzzer Stay 1
688-42725-30-00 Grommet 1
688-82540-11-00 Neutral Switch Ass’y1
663-82554-01-00 Stay, Neutral Switch 1
663-82555-01-00 Damper, Main Switch 1
Steering Friction Ass’y1
• 663-42518-00-00 • Shaft, Friction 1
• 92990-08600-00 • Plate Washer 2
• 663-42528-00-00 • Piece, Friction 1
• 90175-06003-00 • Nut, Wing 1
• 97080-06035-00 • Bolt 1
• 692-42515-01-00 • Rod 1
• 90185-08057-00 • Nut, Lock 1
97013-05010-00 Bolt 2
90185-10051-00 Nylon Lock Nut 2
92990-05100-00 Spring Washer 2
95380-05600-00 Nut 2
63D-83728-00-00 Connector Ass’y. 1
90464-15M11-00 Clamp 3
