2-3
Outboard Rigging Guide - 2001 Engine Mounting Dimensions
Transom Dimensions
MODEL A B C D E F G H I
2 360° 73° 275mm 276mm 417mm 23~60mm 143.7mm 503mm
10.8in 16.4in 3.5in 0.9~2.4in 5.7in 16.8in
3 360° 76° 311mm S: 435mm (17.4in) 105mm 22~60mm 136mm S: 621mm (24.5in)
12.2in 4.1in 0.9~2.4in 5.4in in)
F4 360° 64° 342mm S: 435.1mm (17.1in) 137mm 22~60mm 136mm S: 498.2mm (19.6in)
13.5in L: 562.1mm (22.1in 5.38in 0.9~2.4in 5.4in L: 441.8mm (17.4in)
5 360° 76° 331 mm S: 444mm (17.5in) 134mm 22~60mm 136mm S: 623mm (24.5in)
13.0in 5.3in 0.9~2.4in 5.4in
F6/8 45° 66° 271mm S: 435.5mm (17.1in) 171.5mm 285.5mm 28~67mm 207mm S: 593.5mm (23.4in)
10.7in L:562.5mm (22.1in) 6.8in 11.2in 1.1~2.6in 8.1in L: 669mm (26.3in)
T8P 40° 66° 271mm S: 556.5mm (21.9in) 171.5mm 276mm 33~65mm 326.7mm L: 716mm (28.2in)
10.7in X:624.5mm (24.6in) 6.8in 10.9in 1.3~2.6in 12.9in X: 756.5mm (29.8in)
860° 81° 287mm S: 436mm (17.2in) 137mm 283mm 16~60mm 164mm S: 668mm (26.3in)
11.3in 5.4in 11.1in 0.6~2.1in 6.5in
9.9/15 45° 67° 314mm S:440mm (17.3in) 143mm 280mm 25~63mm 161mm S: 572mm (22.5in)
12.4in 5.6in 11.0in 1.0~2.5in 6.3in
F9.9 37° 70° 270mm S:432mm (17.0in) 166mm) 308mm 33~65mm 170mm S: 598mm (23.5in)
10.6in L:559mm (22.0in) 6.5in 12.2in 1.3~2.6in 6.7in L: 673mm (26.5in)
T9.9 37° 70° 270mm L:559mm (22.0in) 166mm 308mm 33~65mm 170mm L: 716mm (28.2in)
10.6in UL:635mm (25.0in) 6.5in 12.2in 1.3~2.6in 6.7in X: 761mm (30.0in)
F15 45° 63° 475mm S:440mm (17.3in) 183mm 350mm 44mm 164mm S: 572mm (22.5in)
18.7in L:568mm (22.4in) 7.2in 13.8in 1.7in 6.5in L: 641mm (25.2in)
F15P 40° 63° 308.3mm L:569.6mm (22.4in) 182.1mm 329.4mm 33!66mm 326.7mm L: 641mm (25.2in)
12.1in 7.2in 13.0in 1.3~2.6in 12.95in
F25T F:45° F:61° 329mm F:550mm (21.6in) 185mm 400mm 69mm 338mm L:648mm (25.5in)
T25T T:40° T:62° 12.9in T:5280mm (20.8in) 7.3in 14.8in 2.7in 13.3in
F25E 45° 64°
ER:343mm (13.5in) S:423mm (16.6in) 185mm 400mm 37~69mm 21.8mm S:615mm (24.2in)
F25M
EH:363mm (14.3in) L:550mm (21.6in) 7.3in 14.8in 1.5~2.8in 8.6in L:686mm (27.0in)
M:363mm (14.3in)
25 2 CYL 40° 67° 337mm S:419mnm (16.5in) 152mm 296mm 25~70mm 174.3mm S:586mm (23.1in)
13.3in L:546mm (21.5in) 6.,0in 11.7in .98~2.8in 6.9in L:655mm (25.8in)
25/3 40° 70° M:387mm (15.2in) S:424mm (16.7in) 152mm 310mm 30~66mm 245mm S: 584mm (23.0in)
30 E:375mm (14.8in) L:545mm (21.5in) 6.0in 12.2in 1.2~2.6in 9.6in L: 648mm (25.5in)
40M/T 40° M:66° M:433mm (17.0in) L:537mm (21.1in) 175mm 340mm M:30~66mm M:245mm (9.6in) M: 579mm (22.8in)
C40T T:69° T:387mm (15.2in) 6.9in 13.4in (1.2~2.6in) T:355 (14.0in) T: 709mm (27.9in)
T:69mm
(2.7in)
F30T/3 40° 62° 353mm S:410.1mm (16.2in) 189mm 313mm 69mm 338mm S:599.8mm (23.6in)
F40/E/T/3 13.9in L:533mm (21.0in) 7.4in 12.3in 2.7in 13.3in L:665.7mm (26.2in)
F40/M/3 40° 63° 384mm S:410mm (16.1in) 189mm 313mm 69mm 338mm S:604.1mm (24.0in)
15.1in L:533mm (21.0in) 7.4in 12.3in 2.7in 13.3in L:670.8mm (26.4in)
50, C50 40° M:66° M:433mm (17.0in) S:410mm (16.1in) 175mm 340mm M:30~66mm M:245mm (9.6in) M: 579mm (22.8in)
T:69° T:387mm (15.2in) L:537mm (21.1in) 6.9in 13.4in (1.2~2.6in) T:355 (14.0in) T: 709mm (27.9in)
T:69mm
(2.7in)
F50, T50 40° 69° 409mm (16.1in) 533mm (21.0in) 181mm 345mm 69mm (2.7in) 355mm (14.0in) F:709mm (27.9in)
7.1in 13.6in T:696mm (27.4in)
60/70 35° 67° 403mm (15.9in) 520mm 182mm 321mm 69mm 351mm 696
C60/C70 20.5in 7.2in 12.6in 2.7in 13.8in 27.4in
F80/F100 35° 70° 528mm L: 537mm (20.3in) 240mm 405mm 80mm 347mm L:767mm (30.5in)
20.8in X: 664mm (26.2in) 9.5in 16.0in 3.2in 13.7in X:844mm (33.3in)
90/C90 30° 67° 457mm 520mm 187mm 331mm 69mm 351mm 698mm
18.0in 20.5in 7.4in 13.0in 2.7in 13.8in 27.5in
F/LF115 35° 68° 555mm L:516mm (20.3in) 246mm 388mm 82mm 367mm L:773mm (30.5in)
21.8in X:643mm (25.3in) 9.7in 15.3in 3.2in 14.4in X:850mm (33.7in)
115/130 35° 70° 466mm L:517mm (20.4in) 291mm 409mm 82mm 367mm L:775mm (30.5in)
18.4in X:644mm (25.4in) 11.5in 16.1in 3.2in 14.5in X:850mm (33.5in)
150 35° 70° 587mm L:516mm (20.3in) 290mm 406mm 82mm 367mm L:773mm (30.4in)
SX150/200 23.1in X:642mm (25.3in) 11.4in 16.0in 3.2in 14.5in X:849mm (33.4in)
LX150/200
V150 35° 70° 587mm 516mm 290mm 406mm 82mm 367mm 773mm
VX150 23.1in 20.3in 11.4in 16.0in 3.2in 14.5in 30.4in
DX150 35° 70° 587mm 452mm 290mm 406mm 82mm 367mm 695mm
23.1in 17.8in 11.4in 16.0in 3.2in 14.5in 27.4in
VZ150/175 32° 70° 584mm 516mm 277mm 396mm 82mm 367mm 774mm
200 23.0in 20.3in 10.9in 15.6in 3.2in 14.5in 30.5in
Z150~200 32° 70° 574mm L:516mm (20.3in) 277mm 396mm 82mm 367mm L:774mm (30.5in)
LZ150~200 22.6in X:643mm (25.3in) 10.9in 15.6in 3.2in 14.5in X:849mm (33.4in)
VX200/225 35° 70° 624mm 515mm 281mm 419mm 82mm 367mm 768mm
250/3.1L 24.6in 20.3in 11.0in 16.5in 3.2in 14.5in 30.2in
SX225/250 35° 70° 631mm X:642mm (25.3in) 281mm 420mm 79mm 411mm X:846mm (33.3in)
LX225/250 24.8in U:768mm (30.2in) 11.1in 16.5in 3.1in 16.2in U:923mm (36.3in)
