Yamaha F80B - Page 129

6D93G11
6-6
1
2
3
4
5
6
7
8
9
6
No. Part name Q’ty Remarks
1Bolt 2 M6
×
16 mm
2O-ring 1
Not reusable
3 Oil seal 1
Not reusable
4 Oil seal housing 1
5O-ring 1
Not reusable
6 Circlip 1
7 Shift rod 1
8 Woodruff key 1
9Screw 2 ø4
×
12 mm
10 Bolt 2 M8
×
75 mm
11 Cover 1
12 Bolt 2 M8
×
50 mm
13 Seal 1
14 Water pump housing 1
15 Insert cartridge 1
16 Impeller 1
17 Dowel 2
Lower unit
