2-16
SPEC
TIGHTENING TORQUES
Rear shock absorber and frame nut M12 1 40 N·m (4.0 kgf·m, 30 lb·ft)
Mud protector assembly bolt M6 4 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Mud guard and stay bolt M6 4 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Rear stay assembly bolt (LH & RH) M6 8 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Lower chain cover bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Rear fender and swingarm bolt M6 3 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Fuel tank and fuel pump bolt M5 6 4 N·m (0.4 kgf·m, 3.0 lb·ft)
Fuel tank and frame bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Fuel tank bracket and frame bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Fuel tank and fuel tank bracket bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Horn and frame bolt M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Ignition coil and frame bolt M5 2 4 N·m (0.4 kgf·m, 3.0 lb·ft)
Rectifier/regulator and frame bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Side cover and frame screw – 4
1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Rear side cover and frame bolt M6 2 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Seat handle and frame bolt M8 4 21 N·m (2.1 kgf·m, 15 lb·ft)
Seat and frame bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Rear license plate light screw – 1
0.7 N·m (0.07 kgf·m, 0.5 lb·ft )
Rear reflector and rear fender cover nut M5 1
1.5 N·m (0.15 kgf·m, 1.1 lb·ft)
Seat lock and frame bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Battery box and frame bolt M6 2 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Front wheel axle nut M14 1 38 N·m (3.8 kgf·m, 28 lb·ft)
Rear wheel axle nut M14 1 59 N·m (5.9 kgf·m, 44 lb·ft)
Drive chain puller locknut M8 2 14 N·m (1.4 kgf·m, 10 lb·ft)
Rear wheel sprocket nut M8 6 43 N·m (4.3 kgf·m, 32 lb·ft)
Front brake caliper bolt M10 2 35 N·m (3.5 kgf·m, 26 lb·ft)
Front brake caliper sliding pin bolt (long) – 1 23 N·m (2.3 kgf·m, 17 lb·ft)
Front brake caliper sliding pin bolt (small) – 1 14 N·m (1.4 kgf·m, 10 lb·ft)
Front brake disc bolt M8 5 23 N·m (2.3 kgf·m, 17 lb·ft)
Front brake master cylinder holder bolt M6 2 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Brake pedal bolt M10 1 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Front brake caliper bleed screw – 1 14 N·m (1.4 kgf·m, 10 lb·ft)
Air induction system mounting bracket
bolt (at cylinder head)
M6 1 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Sidestand switch bolt M5 2
3.7 N·m (0.37 kgf·m, 2.7 lb·ft)
Under cowling assembly bolt M6 4 5 N·m (0.5 kgf·m, 3.7 lb·ft)
Rear side reflector nut M5 2
1.5 N·m (0.15 kgf·m, 1.1 lb·ft)
Rear side reflector bracket nut M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Item
Thread
size
Q’ty Tightening torque Remarks
