Setting the Stereo Out and Bus Out 1–8 from the Display 101
01V96 Version 2—Owner’s Manual
Bus Outs
8
Routing Bus Out 1–8 Signals to the Stereo Bus.
You can patch Bus Out 1–8 signals to Outputs and Slots 1/2, as well as to the Stereo Bus. You
can adjust the level and pan settings of the signals routed to the Stereo Bus for each bus. This
is convenient when you wish to use Bus Outs (1–8) as a Group Bus.
To patch the Bus Out 1–8 signals to the Stereo Bus, press the DISPLAY ACCESS
[PAN/ROUTING] button repeatedly to display the Pan/Route | Bus to St page.
Move the cursor to the desired parameter you wish to change, then rotate the Parameter
wheel or press the [INC]/[DEC] buttons to modify the setting.
A TO ST PAN
These controls pan the Bus Out 1–8 signals between the left and right Stereo Out buses.
B TO ST ON/OFF
These buttons turn on and off the Bus Out 1–8 to the Stereo Bus routing.
C TO ST Faders
These faders set the Bus Out 1–8 to Stereo Bus levels.
1
2
3
To Next Page
