104 Chapter 8—Bus Outs
01V96 Version 2—Owner’s Manual
Setting the Stereo Out and Bus Out 1–8 from the
Control Surface
You can use the faders, [SEL] buttons, and various buttons and controls in the SELECTED
CHANNEL section on the top panel to directly control certain parameters for the Stereo
Out and Bus Out 1–8.
Setting the Levels
Move the [STEREO] fader to adjust the Stereo Out levels. Press the [ON] button in the STE-
REO section to turn the Stereo Out on or off.
To set Bus Out 1–8 levels, press the [MASTER] button in the LAYER section to select the
Master layer, then move faders 9–16. At this time, you can turn Bus Out 1–8 on or off using
the [ON] 9–16 buttons.
EQ’ing and Balancing the Stereo Out and Bus Outs
1 Press the [SEL] button of the bus to which you want to apply EQ or set the
level balance.
2To adjust the EQ of the currently-selected bus, select the desired band by
pressing one of the following buttons in the SELECTED CHANNEL section:
• [HIGH] button ............ HIGH band
• [H-MID] button ..........HIGH-MID band
• [L-MID] button ...........LOW-MID band
• [LOW] button ..............LOW band
3 Use the [Q], [FREQUENCY], and [GAIN] controls to adjust the Q, frequency,
and gain of the band selected in Step 2.
See page 84 for more information on EQ.
4To adjust the Stereo Out Balance parameter, use the [PAN] control in the
SELECTED CHANNEL section.
Note: If you select Aux Out 1–8 or Bus Out 1–8, the [PAN] control is disabled.
To Next Page
