134 Chapter 11—Monitoring
01V96 Version 2—Owner’s Manual
Using the Solo Function
You can solo and monitor Input Channels, Aux Out 1–8, and Bus Out 1–8 using the
[SOLO] buttons on the top panel.
1 Press the [DIO/SETUP] button repeatedly until the DIO/Setup | Monitor page
appears.
2 Set the SOLO parameter to On.
Set other parameters on the page, if necessary.
3To solo and monitor Input Channels, press the corresponding LAYER button
to select a Layer that contains the desired channels, then press the channel
[SOLO] buttons.
The channel [SOLO] button indicators and the SOLO [SOLO] indicator light up. Only the
soloed Input Channel signals are fed to the Monitor outputs.
4To solo and monitor Output Channels, press the LAYER [MASTER] button,
then press the channel [SOLO] buttons.
Input and Output Channels (Aux Out 1–8, Bus Out 1–8) cannot be solo-monitored simul-
taneously. For example, if you solo an Input Channel, then solo an Output Channel, the
first solo channel is cancelled.
If you solo an Output Channel first, then solo an Input Channel, canceling the Input Chan-
nel’s solo will activate the Output Channel’s solo.
5You can unsolo all soloed channels by pressing all illuminated channel
[SOLO] buttons.
The button indicators turn off. You can also unsolo all soloed channels by pressing the
SOLO [CLEAR] button.
Tip: If the SEL MODE parameter is set to Mix Solo on the DIO/Setup | Monitor page, you
can solo multiple Channels simultaneously.
