Using Libraries 183
01V96 Version 2—Owner’s Manual
Libraries
16
Gate Library
The Gate library enables you to store and recall Input Channel gate settings. The library
contains four preset memories and 124 user (readable & writable) memories.
Follow the steps below to use the Gate library.
1 Press the DISPLAY ACCESS [DYNAMICS] button, then press the [F2] button.
The Dynamics | Gate Lib page appears.
A CURRENT TYPE
This parameter displays the currently-selected channel gate type (Gate or Ducking).
B CURRENT CURVE
This graph displays the current channel gate curve.
C GR meters
These meters indicate the amount of gain reduction being applied by the gate, and the
post-gate levels of the currently-selected channel and its available pair partner.
D Type & Curve section
The type (Gate or Ducking) and curve of the currently-selected memory is displayed
here.
2 Use the LAYER buttons to select layers, then press the [SEL] buttons to select
channels.
You can now store the selected channel gate settings or recall the gate library memories to
channels. For details on storing and recalling memories, see “General Library Operation”
on page 175.
The following table lists the preset memories in the Gate library:
Tip: If you selected an ST IN Channel (1–4), Aux Out (1–8), Bus Out (1–8), or Stereo Out
that does not feature a gate, the 01V96 indicates “XXX has no Gate!” (in which XXX represents
a channel name).
No. Preset Name Type Description
1
Gate
GATE Gate template
2
Ducking
DUCKING Ducking template
3
A. Dr. BD
GATE Gate preset for use with acoustic bass drums
4
A. Dr. SN
GATE Gate preset for use with acoustic snare drums
3
4
1
2
