118 Chapter 9—Aux Outs
01V96 Version 2—Owner’s Manual
3 If you selected the PRE/POST button in Step 2, move the cursor to the desired
Input Channel and Aux intersection, then press the [ENTER] button to
change the signal source point.
4 If you selected the LEVEL button in Step 2, move the cursor to the desired
Input Channel and Aux intersection, then edit the Send level or turn the cur-
rently-selected AUX Send on or off.
Rotate the Parameter wheel or press the [INC]/[DEC] buttons to set the Send level, then
press the [ENTER] button to turn the currently-selected Aux Send on or off.
One of the following indicators appears, depending on the current Aux mode.
• Aux Sends in Fixed mode...................A “FIX” indicator appears for On Aux Sends, and
a dot “ . ” appears for Off Aux Sends.
• Aux Sends in Variable mode..............The current Send levels are displayed by the bar
graphs. If the level is set to nominal (0.0 dB), “N”
appears in the bar. The bars for Aux Sends that
are turned off are highlighted.
Note: You can switch between Pre and Post only for Aux Sends that are set to Variable mode.
The “FIX” indication appears for Aux Sends that are set to Fixed mode, and you cannot switch
Pre/Post.
