250 Appendix A: Parameter Lists
01V96 Version 2—Owner’s Manual
SL-07 Slot CH7 IN SL-07 Slot CH7 IN INS CH23 InsertOut-CH23 AD7 AD IN 7
SL-08 Slot CH8 IN SL-08 Slot CH8 IN INS CH24 InsertOut-CH24 AD8 AD IN 8
SL-09 Slot CH9 IN SL-09 Slot CH9 IN INS CH25 InsertOut-CH25 AD9 AD IN 9
SL-10 Slot CH10 IN SL-10 Slot CH10 IN INS CH26 InsertOut-CH26 AD10 AD IN 10
SL-11 Slot CH11 IN SL-11 Slot CH11 IN INS CH27 InsertOut-CH27 AD11 AD IN 11
SL-12 Slot CH12 IN SL-12 Slot CH12 IN INS CH28 InsertOut-CH28 AD12 AD IN 12
SL-13 Slot CH13 IN SL-13 Slot CH13 IN INS CH29 InsertOut-CH29 AD13 AD IN 13
SL-14 Slot CH14 IN SL-14 Slot CH14 IN INS CH30 InsertOut-CH30 AD14 AD IN 14
SL-15 Slot CH15 IN SL-15 Slot CH15 IN INS CH31 InsertOut-CH31 AD15 AD IN 15
SL-16 Slot CH16 IN SL-16 Slot CH16 IN INS CH32 InsertOut-CH32 AD16 AD IN 16
FX1-1 Effect1 OUT 1 FX1-1 Effect1 OUT 1 INS BUS1 InsertOut-BUS1 2TD-L 2TR IN Dig. L
FX1-2 Effect1 OUT 2 FX1-2 Effect1 OUT 2 INS BUS2 InsertOut-BUS2 2TD-R 2TR IN Dig. R
FX2-1 Effect2 OUT 1 FX2-1 Effect2 OUT 1 INS BUS3 InsertOut-BUS3
FX2-2 Effect2 OUT 2 FX2-2 Effect2 OUT 2 INS BUS4 InsertOut-BUS4
FX3-1 Effect3 OUT 1 FX3-1 Effect3 OUT 1 INS BUS5 InsertOut-BUS5
FX3-2 Effect3 OUT 2 FX3-2 Effect3 OUT 2 INS BUS6 InsertOut-BUS6
FX4-1 Effect4 OUT 1 FX4-1 Effect4 OUT 1 INS BUS7 InsertOut-BUS7
FX4-2 Effect4 OUT 2 FX4-2 Effect4 OUT 2 INS BUS8 InsertOut-BUS8
2TD-L 2TR IN Dig. L 2TD-L 2TR IN Dig. L INS AUX1 InsertOut-AUX1
2TD-R 2TR IN Dig. R 2TD-R 2TR IN Dig. R INS AUX2 InsertOut-AUX2
INS AUX3 InsertOut-AUX3
INS AUX4 InsertOut-AUX4
INS AUX5 InsertOut-AUX5
INS AUX6 InsertOut-AUX6
INS AUX7 InsertOut-AUX7
INS AUX8 InsertOut-AUX8
INS ST-L InsertOut-ST-L
INS ST-R InsertOut-ST-R
INPUT INSERT IN EFFECT IN CASCADE
