268 Appendix A: Parameter Lists
01V96 Version 2—Owner’s Manual
DELAY+REV
One input, two output delay and reverb effects in
parallel.
DELAY->REV
One input, two output delay and reverb effects in
series.
DIST->DELAY
One input, two output distortion and delay effects in
series.
MULTI FILTER
Two input, two output 3-band multi-filter (24
dB/octave).
Parameter Range Description
DELAY L 0.0–1000.0 ms Left channel delay time
DELAY R 0.0–1000.0 ms Right channel delay time
FB. DLY 0.0–1000.0 ms Feedback delay time
FB. GAIN –99 to +99%
Feedback gain (plus values for
normal-phase feedback, minus
values for reverse-phase feed-
back)
DELAY HI 0.1–1.0
Delay high-frequency feedback
ratio
HPF
THRU,
21.2 Hz–8.00 kHz
High-pass filter cutoff frequency
LPF
50.0 Hz–16.0 kHz,
THRU
Low-pass filter cutoff frequency
DLY.BAL 0–100%
Delay and reverb balance (0% =
all delay, 100% = all reverb)
REV TIME 0.3–99.0 s Reverb time
INI. DLY 0.0–500.0 ms Initial delay before reverb begins
REV HI 0.1–1.0 High-frequency reverb time ratio
DIFF. 0–10 Spread
DENSITY 0–100% Reverb density
SYNC OFF, ON Tempo parameter sync on/off
NOTE L
1
1.
(Maximum value depends on the tempo setting)
Used in conjunction with
TEMPO to determine left chan-
nel DELAY L
NOTE R
1
Used in conjunction with
TEMPO to determine right chan-
nel DELAY R
NOTE FB
1
Used in conjunction with
TEMPO to determine FB. DLY
Parameter Range Description
DELAY L 0.0–1000.0 ms Left channel delay time
DELAY R 0.0–1000.0 ms Right channel delay time
FB. DLY 0.0–1000.0 ms Feedback delay time
FB. GAIN –99 to +99%
Feedback gain (plus values for
normal-phase feedback, minus
values for reverse-phase feed-
back)
DELAY HI 0.1–1.0
Delay high-frequency feedback
ratio
HPF
THRU,
21.2 Hz–8.00 kHz
High-pass filter cutoff frequency
LPF
50.0 Hz–16.0 kHz,
THRU
Low-pass filter cutoff frequency
DLY.BAL 0–100%
Delay and delayed reverb bal-
ance (0% = all delayed reverb,
100% = all delay)
REV TIME 0.3–99.0 s Reverb time
INI. DLY 0.0–500.0 ms Initial delay before reverb begins
REV HI 0.1–1.0 High-frequency reverb time ratio
DIFF. 0–10 Spread
DENSITY 0–100% Reverb density
SYNC OFF, ON Tempo parameter sync on/off
NOTE L
1
Used in conjunction with
TEMPO to determine left chan-
nel DELAY L
NOTE R *1
Used in conjunction with
TEMPO to determine right chan-
nel DELAY R
NOTE FB *1
Used in conjunction with
TEMPO to determine FB. DLY
1.
(Maximum value depends on the tempo setting)
Parameter Range Description
DST TYPE
DST1, DST2,
OVD1, OVD2,
CRUNCH
Distortion type (DST = distor-
tion, OVD = overdrive)
DRIVE 0–100 Distortion drive
MASTER 0–100 Master volume
TONE –10 to +10 Tone control
N. GATE 0–20 Noise reduction
DELAY 0.0–2725.0 ms Delay time
FB. GAIN –99 to +99%
Feedback gain (plus values for
normal-phase feedback, minus
values for reverse-phase feed-
back)
HI. RATIO 0.1–1.0 High-frequency feedback ratio
FREQ. 0.05–40.00 Hz Modulation speed
DEPTH 0–100% Modulation depth
DLY.BAL 0–100%
Distortion and delay balance
(0% = all distortion, 100% = all
delayed distortion)
SYNC OFF, ON Tempo parameter sync on/off
DLY.NOTE
1
1. (
Maximum value depends on the tempo setting)
Used in conjunction with
TEMPO to determine DELAY
MOD.NOT
E
2
2.
Used in conjunction with
TEMPO to determine FREQ.
Parameter Range Description
TYPE 1 HPF, LPF, BPF
Filter 1 type: high pass, low pass,
band pass
TYPE 2 HPF, LPF, BPF
Filter 2 type: high pass, low pass,
band pass
TYPE 3 HPF, LPF, BPF
Filter 3 type: high pass, low pass,
band pass
FREQ. 1 28.0 Hz–16.0 kHz Filter 1 frequency
FREQ. 2 28.0 Hz–16.0 kHz Filter 2 frequency
FREQ. 3 28.0 Hz–16.0 kHz Filter 3 frequency
LEVEL 1 0–100 Filter 1 level
LEVEL 2 0–100 Filter 2 level
LEVEL 3 0–100 Filter 3 level
RESO. 1 0–20 Filter 1 resonance
RESO. 2 0–20 Filter 2 resonance
RESO. 3 0–20 Filter 3 resonance
Parameter Range Description
To Next Page
