Yamaha PSR-A3000 User Manual

PSR-A3000 Owner’s Manual 183
Mixing Console
9
Editing TUNE Parameters
[A]/[B]/
[F]/[G]
PORTAMENTO
TIME
Portamento is a function that creates a smooth transition in pitch from the
first note played on the keyboard to the next. The Portamento Time deter-
mines the pitch transition time. Higher values result in a longer pitch
change time. Setting this to “0” results in no effect. This parameter is avail-
able when the selected keyboard part is set to MONO (page 114).
[C]/[H] PITCH BEND
RANGE
Determines the pitch bend range for each keyboard part which is affected
by controlling the joystick (when the Pitch Bend function is assigned;
page 40). The range is from “0” to “12” with each step corresponding to
one semitone.
[D]/[I] OCTAVE Determines the range of the pitch change in octaves, over two octaves up or
down for each keyboard part. The value set here is added to the setting
made via the UPPER OCTAVE [-]/[+] buttons.
[E]/[J] TUNING Determines the pitch of each keyboard part in cents.
NOTE In musical terms a “cent” is 1/100th of a semitone. (100 cents equal one semitone.)
[1 ]–
[3 ]
TRANSPOSE Allows you to set transposition for the overall sound of the instrument
(MASTER), Song playback (SONG), or the keyboard pitch (KBD), respec-
tively. Please note that the “KBD” setting also transposes the pitch of Style
playback and the Multi Pads (since these are also affected by keyboard play
in the left-hand section).

Yamaha PSR-A3000 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black, Grey
Sound effects	Flanger/Digital Signal Processing (DSP), Reverberation
RMS rated power	30 W
Number of speakers	2
Chorus effects quantity	106
Keyboard number of keys	61
Preset programs quantity	4
Maximum polyphony (notes)	128
Display type	LCD
Display diagonal	7 \
Power source type	DC

Weight and Dimensions

Depth	437 mm
Width	1002 mm
Height	148 mm
Weight	11200 g
