CHAPTER2 PROFIBUS Unit
(2) Current program number read .............................................. Code 0202
The execution program number is read.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
Program number
(Details)
Program number:
It is the inherent number of 0 to 99 assigned to each program.
(Example)
Transmission example 1:
The execution program is read.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0000
0000 0000
0000 0202
Response example 1:
No. 31 is being executed.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 001F
0000 0200
