16
CHAPTER2 PROFIBUS Unit
SO216
SO217
SO218
SO219
SO220
SO221
SO222
SO223
SO224
SO225
SO226
SO227
SO228
SO229
SO230
SO231
Not Used
Im+4.0
Im+4.1
Im+4.2
Im+4.3
Im+4.4
Im+4.5
Im+4.6
Im+4.7
Im+5.0
Im+5.1
Im+5.2
Im+5.3
Im+5.4
Im+5.5
Im+5.6
Im+5.7
Im+6.0
to Im+7.7
SI216
SI217
SI218
SI219
SI220
SI221
SI222
SI223
SI224
SI225
SI226
SI227
SI228
SI229
SI230
SI231
Not Used
Qn+4.0
Qn+4.1
Qn+4.2
Qn+4.3
Qn+4.4
Qn+4.5
Qn+4.6
Qn+4.7
Qn+5.0
Qn+5.1
Qn+5.2
Qn+5.3
Qn+5.4
Qn+5.5
Qn+5.6
Qn+5.7
Qn+6.0
to Qn+7.7
OUTPUT (Slave→Master) INPUT (Master→Slave)
Address Signal Name Address Signal Name
* Use Im.0 to Im+1.7 as dedicated outputs, Im+2.0 to Im+5.7 as general-purpose out-
puts, Qn.0 to Qn+1.7 as dedicated inputs, and Qn+2.0 to Qn+5.7 as general-purpose
inputs.
*Im+6.0 to Im+7.7 and Qn+6.0 to Qn+7.7 are not used.
!
CAUTION
•The above profile is for cases where the I/O assignment selection parameter is
set to "Type 0: Conventional type" when the controller has an I/O assignment
function. For information on the profile when the I/O assignment selection pa
rameter is set to another type, refer to "2-9-2 I/O assignment list".
•The zone output is supported by the following controller versions:
ERCX, SRCX : Ver. 13.50 or later DRCX : Ver. 18.50 or later
SRCP, SRCD : Ver. 24.00 or later SRCP30 : Ver. 24.30H or later
Remote Register (Word I/O)
Status
Reserved
Command response
-
0
0
0
0
IWm+8
IWm+10
IWm+12
IWm+14
IWm+16
IWm+18
IWm+20
IWm+22
Execution command
Command option
QWn+8
QWn+10
QWn+12
QWn+14
QWn+16
QWn+18
QWn+20
QWn+22
OUTPUT (Slave→Master) INPUT (Master→Slave)
Address Description Address DescriptionDefault Default
*For details on the remote register, refer to "2-12 Remote Command".
What each code means:
Codes used above are written on the basis of the digital I/O address designated in a
master manufactured by Siemens.
I: Input address
Q: Output address
m, n : Start address assigned by hardware configuration
