3-
20
3
I/O INTERF
ACE
3-6-3
When interlock signal is input
LOCK
BUSY
END
Interlock
Dedicated
command
Differs according to execution command
■
When a interlock signal is input while a dedicated command is being ex
ecuted, the BUSY
signal turns off.
The READ
Y and END signals remain unchanged.
3-6 I/O Control Timing Charts
