PARAMETERS
5-1 Setting the Parameters
5-1 Setting the Parameters
1) On the initial screen, press
F3
(SYS).
[SYS-PRM-COM]
PRM0 = 4
JMPF DI number
range 1 to 8
[SYS-PRM-COM]
PRM1 = 0
alarm output
0:OFF 1:ON 2:ON(DO6)
[MENU]
select menu
1EDIT2OPRT3SYS 4MON
[SYS]
select menu
1PRM 2B.UP3INIT
[SYS-PRM-X]
PRM48 = 450 [mm]
(+)soft limit
range -9999→9999
[SYS-PRM]
select menu
1COM 2X 3Y
2) Next, press
F1
(PRM).
3) When editing the common parameters, press
F1
(COM).
4) The current PRM0 (number of conditional in-
put points) setting appears on the screen. Use
the
STEP
UP
and
STEP
DOWN
keys to scroll the parameters
until you find the parameter you want to set.
5) When the desired parameter is displayed, enter
the new value with the number keys and then
press .
6) When editing the X-axis parameters, press
F2
(X) in step 3. Likewise, when editing the
Y-axis parameters, press
F3
(Y) in step 3.
